- Material
- Plastic
- Receiving frequency
- 2.400GHz~2.480GHz
- Video format
- PAL/NTSC automatic switching
- Working temperature
- -20~60℃/-10~50℃
- Resolution (dot)
- 480(W) x 240(H)
- Receiving sensitivity
- ≤-85dBm
- LCD screen
- 3.5'' TFT LCD
- Low voltage shutdown
- automatic shutdown when the battery is below 3.4V
- Adapter power supply
- DC5V/1000MA MicroUSB
- Product size
- 130mm*74mm*16mm, 65*mm*32mm*105mm
- Receiving signal
- image, sound
- Built-in battery
- 1000MA
- Power consumption
- ≤3W
- Transmitting frequency
- 2.400GHz~2.480GHz
- Transmit power
- 17dBm
- Effective pixels
- 628(H) x 582(V) 510(H) x 492(V)
- Imaging device
- 1/4 "CMOS image sensor
- Horizontal resolution
- 380TV Line
- Send signal
- image, sound
- Minimum illumination
- 0Lux (Infrared LED on) / 5LUX (IR off)
- Open transmission distance
- 100 meters
- Weight
- 400 g
